M-7043D CR ICP DAS DCON Modbus



The I-7042 offers 13 channels digital output channels, each of which features Photocouple isolation and supports sink-type output using an open collector. There are also options to enable both power-on and safe values. The I-7042D has 13 LED indicators that can be used to monitor the status of DO channels. 3750 Vrms intra-module isolation is standard. The I-7043 offers 16 digital output channels, each of which are non-isolated and support sink-type output using an open collector. There are also options to enable both power-on and safe values. The I-7043D has 16 LED indicators that can be used to monitor the status of DO channels. The hardware specifications for the M-7043 are the same as the I-7043, and both support the Modbus RTU and DCON protocols, which can be configured via software.





Watchdog Timer: Yes, Module (1.6 Seconds), Communication (Programmable)



Type: I/O LED Indicator



Status: 1 x Power and Communication

16 x Digital Output



Channels: 16

Type: Open Collector

Sink/Source (NPN/PNP): Sink

Load Voltage: +10 ~ 30 VDC

Load Current: 100 mA/Channel

Power on Value: Yes

Safe Value: Yes



Ports: 1 x RS-485

Baud Rate: 1200 to 115200 bps

Data Format: (N, 8, 1) (N, 8, 2) (E, 8, 1) (O, 8, 1)

Protocol: Modbus RTU, DCON



Reverse Polarity Protection: Yes

Input Range: +10 ~ +30 VDC

Consumption: 1.1 W



Dimensions (mm): 123 x 72 x 35 (W x L x H)

Installation: DIN-Rail



Operating Temperature: -25 ~ +75 °C

Storage Temperature: -40 ~ +85 °C

Humidity: 10 ~ 95% RH, Non-condensing
