DIN-KA52F
Power Supply/48V/0,52A/25W/DIN-Rail
- Universal input voltage
- 3 pole AC inlet IEC320-C14
- Class power (with earth pin)
- Protections: Short circuit / Overload / Over voltage
- PWM 3842 control circuit and regulated
- Approvals: UL / CUL / TUV / BSMI / CB / FCC / CE
Input
Voltage range: 100-250VAC
Frequency: 50/60Hz
Input current: 40A / 230VAC
LEAKAGE CURRENT(max.): 0.75mA / 240VAC
Output
Voltage: 24VDC
Output current: 1.04A
Ripple: 180mVp-p
Over voltage protection: Yes (clamp by Zener diode).
Over current protection:
130 ~ 180% rated output power
Protection type: Hiccup mode, recovers automatically after fault condition is removed
Over load protection:
105 ~ 135% rated output voltage
Protection type: Recovers automatically after fault condition is removed
Temperature coefficient: ±0.04%/°C (0~50°C)
Efficiency: 82% (Typ.)
Hold-up time: 16ms at full load
Line regulation: ±1% (Line regulation is measured from low line to high line at rated load)
Load regulation: ±2% (Load regulation is measured from 20% to 100% rated load)
General
MTBF: 500Khrs min. MIL-HDBK-217F(25°C)
Environmental
Operating Temperature: 0 °C ~ +50°C
Storage Temperature: -20 °C ~ +85°C
Humidity: 20% ~ 90% RH, non-condensing
Derating: Derated from 100% at +38 °C
SAFETY & EMC
Safety standards: UL60950-1, CSA C22.2, TUV EN60950-1, BSMI CNS14336 approved
Withstand voltage: I/P-O/P:3KVAC , I/P-FG:1.5KVAC
Isolation resistance: I/P-O/P, I/P-FG:100M Ohms / 500VDC / 25 / 70% RH
EMI conduction & radiation: Compliance to EN55022 class B, FCC PART 15 / CISPR22 class B, CNS13438 class B
Harmonic current: Compliance to EN61000-3-2,3
EMS IMMUNITY: Compliance to EN61000-4-2,3,4,5,6,11, light industry level, criteria A
