DB-24C/D/DIN CR, 4-ch Open Collector Output Board with DIN-rail Mounting Include: CA-3710 (DB37 Male to Male, 45°, 1M)
DB-24C/D/DIN CR
4-ch Open Collector Output Board with DIN-rail Mounting Include: CA-3710 (DB37 Male to Male, 45°, 1M)
Free Shipping
Features
- 24 open-collector output (NPN)
- One OPTO-22 Compatible Connector and one 37 pin D-sub connector and one 20-pin connector
- 24 channel max. load 600mA (per channel)
- Max. laod voltage : 30 VDC
- LED’s indicated output status
- Screw terminals for easy field wiring
Introduction
The DB-24C has 24 channels of optically isolated digital outputs, arranged into four isolated banks.
Applications
- On/off control
- Energy management
- Test Automation
- Process Control
Specifications
Digital Output
Channels: 24
Type: Open Collector
Load Current: (100mA/30Vdc)x16; (600mA/30Vdc)x8
Response Speed: 1 kHz (Typical)
Isolation: 3750 Vrms
Power
Consumption: 400 mA @ 5 V
Mechanical
Dimensions (mm): 170 mm x 114 mm
Installation: DIN-rail mounting
Environment
Operating Temperature: 0 ~ 60°C
Storage Temperature: -20 ~ 70°C
Humidity: 5% to 90 % noncondensing
